Technische Parameter
Nominal Voltage | 3.2V |
Charging Cut-off Voltage | 3.65V |
Discharging Cut-off Voltage | 2.5 V |
Standard Charging Current | 80A |
Standard Discharging Current | 80A |
Weight | 3000±100g |
25 ℃ Cycle | 4000 Cycles |
Charging Temperature | -10~ 65 ℃ |
Discharging Temperature | -35 ~ 65 ℃ |
Dimension | H:153.5±0.50 mm L: 173.90±0.50 mm T:53.85±0.50 mm |
Model Name | LF160 |
Nominal Capacity | 160Ah |
Abmessungen der Batterie
